Fluke 772 毫安过程钳型表
名称：钳形表
品牌：
型号：
简介：Milliamp process clamp meters can measure mA signals without breaking the loop. The Fluke 772 mA Clamp Meter expand upon...
申请服务
- 产品介绍
Need more hours in your day?
Save time by NOT breaking the loop on 4-20 mA signal measurements.
Are you spending time:
Taking mA measurements by removing a wire and breaking the loop
Calling the control room to isolate a loop
Testing analog input/output on a console
Troubleshooting devices with mA inputs and outputs
Repairing intermittent or erratic 4-20 mA loops
Going back to the shop to get extra tools
If you need more time in your busy day take a good look at the Fluke 772 mA Clamp Meters. It’s designed to save you time, and money, by eliminating time wasting activities. Now you can troubleshoot and repair 4-20 mA loops without breaking the loop or bringing down the system.
you spending time:
Taking mA measurements by removing a wire and breaking the loop
Calling the control room to isolate a loop
Testing analog input/output on a console
Troubleshooting devices with mA inputs and outputs
Repairing intermittent or erratic 4-20 mA loops
Going back to the shop to get extra tools
If you need more time in your busy day take a good look at the Fluke 772 mA Clamp Meters. It’s designed to save you time, and money, by eliminating time wasting activities. Now you can troubleshoot and repair 4-20 mA loops without breaking the loop or bringing down the system.
Here are some specific ways the Fluke 772 Clamp Meters will help you:
Milliamp Clamp Features
Application
How it saves time and money
Measure mA signals for PLC and control system analog I/O without breaking the loop
Measures low level dc current
Correlate process indication with real physical value
Measure output signals from transmitters without breaking the loop
Maintain and troubleshoot process and automation equipment without breaking the loop
No disruption to the process
Detachable clamp with extension cable
Measurements in tight locations
Enables measurements in difficult situations
Measurement Spotlight
Illuminates hard to see wires in dark enclosures
Measurement process is easier and quicker
Measure up to 99.9 mA range non-contact
Wide range of measurements
Measures 10 to 50 mA signals in older control systems
Automatic power off
After 15 minutes and 2 minute automatic off for backlight and spotlight
Saves battery life
Fluke 772 mA 钳表的功能:
最佳的 0.2% 准确度
0.01 mA 分辨率和灵敏度
无需“断开回路即可测量 4 至 20 mA 信号
测量 PLC 和控制系统模拟 I/O 的 mA 信号
可显示 mA 测量值和 4 至 20 mA 量程百分比的双背光显示屏
测量聚光灯照亮黑暗机箱内难以发现的线路
具有延长线的可拆式钳表，可在狭小的空间中进行测量
使用 99.9 mA 量程测量旧控制系统中的 10 至 50 mA 信号
自动更改 4 至 20 mA 输出以便进行远程测试
自动关闭、背光超时等省电功能可延长电池寿命
“保持功能可捕获和显示不断变化的测量值
通过表笔“接入回路测量功能测量 4 至 20 mA 信号
同步24V回路供电并测量回路mA信号，可为传送装置供电并对其进行测试
输出 4 至 20 mA 信号源以测试控制系统 I/O 或 I/P
mA 输出线性渐变或 25% 分步输出
自动更改 4 至 20 mA 输出以便进行远程测试
环境技术指标
可测量导线的直径 0.177 或 4.5 mm（最大值）
操作温度 -10 至 50 ºC
存放温度 -25 至 60ºC
操作湿度 < 90% @ <30 ºC, < 75% @ 30 至 55ºC
操作海拔高度 0 至 2000 m
IP 等级 IP 40
尺寸 59 x 38 x 212 mm, (2.32 x 1.5 x 8.35 in.)
重量 260G, (9.1 oz.)
振动 随机 2 g, 5 至 500 Hz
撞击 1 米落体试验（钳夹除外）
EMI/RFI 符合 EN61326-1 标准
注:对于采用钳夹的电流测量，应将 1mA 添加至值为 1V/m（最多为 3V/m）的 EMC 场强的指术指标。
温度系数 0.01% ºC
(<18? 或 > 28?)
电源，电池寿命 (2) 节 AA 1.5 V 碱性电池，IEC LR6，通常 40 小时
保修 电子元件保修三年, 电缆和钳表组件保修一年
功能技术指标
mA 测量
（由钳表测量）
分辨率和量程: 0 至 20.99 mA
准确度: 0.2% + 2 位数
分辨率和量程: 21.0mA 至 100.0 mA
准确度: 1% + 5 位数
mA 测量
（由钳表测量）
分辨率和量程: 分辨率和量程: 0 至 24.00 mA
准确度: 0.2% + 2 位数
mA 输出 (最大 mA 驱动:
24 mA进入 1,000 欧姆负载)
分辨率和量程: 分辨率和量程: 0 to 24.00 mA
准确度: 0.2% + 2 位数
mA 模拟
(最大电压 50 V dc)
分辨率和量程: 分辨率和量程: 0 to 24.00 mA
准确度: 0.2% + 2 位数
