SEA LED 20 |
SEA LED 60 |
SEA LED 125 |
SEA LED 250 |
|
|
输入功率
|
20W (=50W 卤素灯) |
60W (=150W 卤素灯) |
100W (=300W 卤素灯) |
200W (=600W 卤素灯) |
|
照 度
|
1,000 Lumen | 3,000 Lumen | 7,500 Lumen | 15,000 Lumen |
|
色 温
|
3,200 K | 3,200 K | 3,200 K | 3,200 K |
|
光束角度
|
40°(70°可选) | 30°/ 60° | 25°/ 40°/ 70° | 25°/ 40°/ 70° |
|
光照调节
|
0 – 100 % | 0 – 100 % | 0 – 100 % | 0 – 100 % |
|
调节电压
|
0 – 10 VDC |
RS232, 0-10VDC / 24 VDC step |
Triac / 0-10 VDC | Triac / 0-10 VDC |
|
外壳材质
|
双相不锈钢 | 硬质氧化铝 | 硬质氧化铝 | 硬质氧化铝 |
|
LED 寿命
|
50,000 小时 | 50,000 小时 | 50,000 小时 | 50,000 小时 |
|
尺 寸
|
30×76 mm | 65×116 mm | 76×139×48 mm | 101×166×48 mm |
|
重 量
|
0.30 kg / 0.20 kg | 0.70 kg / 0.20 kg | 0.85 kg / 0.60 kg | 1.30 kg / 1.00 kg |
|
工作水深
|
1,500 m | 3,000 m | 3,000 m | 3,000 m |
|
工作电压
|
24 VDC | 24 VDC / 110 VAC | 110 VAC | 110 VAC |
|
温度采集
|
Yes | Yes | Yes | Yes |
关键词：水下LED照明灯，
